FBE Coated LSAW Pipe

Type: FBE (Fusion Bond Epoxy) Coated Pipe, Epoxy Coated Carbon Steel Pipe

Application: Used for natural gas, petroleum, water & sewage, and pipe systems

Specification: Outer diameter: 219mm~2020mm

                         Wall thickness: 5mm~25mm

                         LENGTH: 4mtr, 6mtr, 12mtr, 18mtr, 21mtr

Coating Standard: DIN 30670, DIN 30671, DIN 30678, SY/T0413-2002 etc.

Pipe Type: Submerged Arc Welded (LSAW/SSAW), Electrci Resistance Welded

End:Plain End/Bevelled End, Burr Removed

Surface: One Layer / Double Layer FBE anti-corrosive coating powder (200um~800um)

Packing: Waterproof Paper wrapped, Steel Strips bundled, two tags on each bundle

Contact us :

Email:sales@sunrisesteelgroup.com

Whatsapp:+0086-13875806221

Phone:+0086-13875806221

Skype:wycsky1

DescriptionProcessEquipment Inquiry

Type: FBE (Fusion Bond Epoxy) Coated Pipe, Epoxy Coated Carbon Steel Pipe

Application: Used for natural gas, petroleum, water & sewage, and pipe systems

Specification: OD: 219mm~2020mm

                         WT: 5mm~25mm

                         LENGTH: 4mtr, 6mtr, 12mtr, 18mtr, 21mtr

Coating Standard: DIN 30670, DIN 30671, DIN 30678, SY/T0413-2002 etc.

Pipe Type: Submerged Arc Welded (LSAW/SSAW), Electrci Resistance Welded

End:Plain End/Bevelled End, Burr Removed

Surface: One Layer / Double Layer FBE anti-corrosive coating powder (200um~800um)

Packing: Waterproof Paper wrapped, Steel Strips bundled, two tags on each bundle


Long Term Corrosion Protection

FBE’s excellent adhesion to steel provides superior long term corrosion resistance and protection of pipelines operating at moderate temperatures for the designed life.
Superior adhesion properties provide excellent resistance to cathodic disbondment which reduces the total cost of cathodic protection during the operation of the pipeline.


Engineered Solutions

Advanced manufacturing techniques allow FBE to be customized to your specific project.
Can be applied to various pipe diameters from 90 mm (3.5”) to over 1220 mm (48”).
Can be applied in a wide range of thicknesses to cost effectively meet unique project specifications and performance requirements.


Good Mechanical and Chemical Protection
FBE can be applied as a dual layer product which provides tough physical properties that minimize damage during handling, transportation, installation and operation.
FBE has been designed for good chemical resistance under most soil conditions.


Looking forward to your favourable inquiry!
